SPRINT base.line

Single-sided drilling and dowel insertion machine for batch size 1 production – basic equipment

Pure function, top quality and consistent high performance are combined into one in the basic version of our SPRINT drilling and dowel insertion machine.

The machine is equipped for horizontal drilling and doweling. However, to achieve maximum processing flexibility, it can be additionally equipped with a vertical drilling station for drillings in the border area. The proven technology guarantees high-quality drilling and doweling results -consistently over long periods- and reproducible accuracy thanks to perfect precision.

Faster production processes and exact reproduction are an ideal combination to make perfectly precise dowel joints for products such as

  • Casegoods
  • Drawers
  • Cabinet and furniture frame parts
  • Solid wood rails, stiles, jambs and posts

  • Extreme efficiency due to the possibility to process 4 workpieces simultaneously
  • Fast drilling operations due to strong drilling systems
  • Easy, self-explaining machine handling due to the new KOCH user interface
  • Clean drill holes and precise positioning of dowels
  • High precision due to solid and robust design
  • Maximum availability due to brand-name and quality components
  • 18,5“ screen with Beckhoff control and network connection

  • 4 working fields
  • Max. workpiece width: 1,300 mm / 51.18”
  • Horizontal drilling station with 1 drilling spindle
  • Glue injecting and dowel insertion station
  • KOCH WOP - parametric programming
  • 3 stops manually lowerable (center and side stops)
  • Windows 10
  • Premium Remote Support
  • Central lubrication

  • Stock width: 1,800 mm (70.87”) / 2,500 mm (98.43”)
  • Vertical drilling station from above with 1 drilling spindle
  • ELC – Electronic Glue Control
  • NC-positioning of height adjustment of drilling and dowel insertion station (Z-axis)
  • Automatic detection of stock width
  • Bar code reader
  • Low voltage supply USV
